3/4" Very Heavy Duty Impact Ratchet

CP772H
One hand push button forward/reverse power regulator. Four positive power settings in forward and ultimate power in reverse. Teasing throttle design for precise control. Handle exhaust with 360° air inlet swivel to prevent hose kinks. Comfortable contoured handle grip reduces user fatigue. Hammer mechanism DynaPactTM clutch. Pin clutch oil bath.

Output drive: 3/4”.
Air inlet thread: 3/8” NPT.
Free speed: 4,200rpm.
Air consumption: 6.0cfm.
Air pressure: 90psi.
Standard bolt capacity: 1”.
Working torque range: 150 - 700Nm.
Max. Torque @90psi rev: 1356Nm.
Sound pressure level: 96dBA.
Vibration level: 4.9m/s2.
Overall length: 245mm.
Weight: 4.76kg.



*Based on a 15 second cycle per minute average use.
