Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'B' Shape. Shank Diameter 3mm

Shape B122. Grade: RA120. Diameter: 10mm. Length: 10mm. Max. rpm: 61,000. Weight per 10: 40g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'A' Shape. Shank Diameter 6mm

Shape A2. Grade: RA46. Diameter: 25mm. Length: 32mm. Max. rpm: 38,000. Weight per 10: 380g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'A' Shape. Shank Diameter 6mm

Shape A12. Grade: RA46. Diameter: 18mm. Length: 32mm. Max. rpm: 48,000. Weight per 10: 210g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'W' Shape. Shank Dia. 3mm

Shape W146. Grade: RA80. Diameter: 3mm. Length: 13mm. Max. rpm: 100,000. Weight per 10: 20g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'W' Shape. Shank Dia. 6mm

Shape W217. Grade: RA46. Diameter: 25mm. Length: 10mm. Max. rpm: 38,000. Weight per 10: 40g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'A' Shape. Shank Diameter 6mm

Shape A4. Grade: RA46. Diameter: 32mm. Length: 32mm. Max. rpm: 30,000. Weight per 10: 440g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'B' Shape. Shank Diameter 3mm

Shape B123. Grade: RA80. Diameter: 5mm. Length: 5mm. Max. rpm: 100,000. Weight per 10: 20g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'W' Shape. Shank Dia. 6mm

Shape W188. Grade: RA60. Diameter: 13mm. Length: 38mm. Max. rpm: 30,370. Weight per 10: 220g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'B' Shape. Shank Diameter 3mm

Shape B103. Grade: RA80. Diameter: 16mm. Length: 5mm. Max. rpm: 61,000. Weight per 10: 40g.

Kennedy® Mounted Points and Wheels

Suitable for portable die and straight hand grinders. All points are aluminium oxide with "rubenite" as standard for all general purpose grinding and deburring on steels and most metals. Silicon carbide grade (suitable for stone/non-ferrous grinding) available on request. Shank diameters are metric as listed below with inch sizes available on request. Maximum speeds are quoted assuming that collet to back of point does not exceed 12.7mm (1/2") and are for guidance only.

'W' Shape. Shank Dia. 3mm

Shape W173. Grade: RA80. Diameter: 10mm. Length: 3mm. Max. rpm: 70,000. Weight per 10: 30g.
