Guhring M42 2 Flute Slot Drills Weldon Shank

Short rigid slot drills to suit all general-purpose applications, including alloyed steels, stainless steels and non-ferrous materials. Uncoated.

For all dimensional and technical specifications please refer to our catalogue.

Series 3451 2 Flute Slot Drills

Available in sizes: 3, 4, 5, 6, 8 and 10mm.

SwissTech 4 & 6 Flute End Mills Weldon Shank HSS-Co 8%

Centre cutting. Weldon shank to DIN 1835B.
Shank cutting diameter:
3-6mm to plus0.04 -0.0.
8-20mm to plus0.05 -0.0.

Available in HSS-Co 8% Uncoated (for general production machining), HSS-Co 8% TiCN Coated (extends cutter life and improves work material surface finish) and HSS-Co 8% TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).

For all dimensional specifications please refer to our catalogue.

Series 10 Long EMN-4WL TiCN Coated

Dimensions to DIN 844.

Kennedy® Milling Cutters Plain Shank Carbide Micrograin

3 Flute
Centre cutting as standard. Offer a combination of advantages achieved with two and four flutes giving profile and peripheral milling capability in addition to slotting and plunging. Manufactured to Works Standards.

For all dimensional and technical specifications please refer to our catalogue.

Regular Series 3 Flute Slot Drills - Inch

Guhring High Performance Unequal Helix Carbide Milling Cutters

Up to 60% higher feed rates.
Longer tool life.
Vibration free machining.
Suitable for roughing and finishing.
Increased surface quality.
Made to DIN 6527.
4 Flute Weldon Shank End Mill 40°/42°
Bright finish. Uncoated.
Suitable for aluminium and soft materials.
Sizes: 6, 8, 10, 12, 16 and 20mm.

SwissTech 2 Flute Slot Drills Weldon Shank HSS-Co 8%

Centre cutting. Weldon shank to DIN 1835B. Cutting diameter to e8. Shank diameter to h6. Available in HSS-Co 8% Uncoated (for general production machining), HSS-Co 8% TiCN Coated (extends cutter life and improves work material surface finish) and HSS-Co 8% TiALN Coated (dissipates and resists heat, reduces surface friction coupled with high surface hardness).

For all dimensional specifications please refer to our catalogue.

Series 02 Regular SDN-2WR TiCN Coated

Dimensions to DIN 844.

Kennedy® 2 Flute Milling Cutters for Aluminium Carbide Al-Karb Ultrafine Micrograin

Centre cutting as standard. An advanced tool geometry designed for cutting aluminium and other non-metallic, non-ferrous materials requiring high machining rates. Al-Karb cutters will out-perform conventional end mills on these materials as the flute design allows maximum chip removal.Short Series

Short Series 2 Flute - Inch

Kennedy® Milling Cutters Throwaway Micro-Grain Solid Carbide

For high volume production. Compatible with standard automatic locking chucks and spindle adaptors (available on request).

Long Series - Metric

Kennedy® Ball Nosed Slot Drills Plain Shank Carbide Micrograin

For maximum strength when milling harder materials where rapid swarf removal is not needed. 4 flute milling cutters have one of the strongest tooth structures available in solid cutters. Centre cutting as standard. Manufactured to ANSI Standards.

For all dimensional and technical specifications please refer to our catalogue.

Regular Series 4 Flute - Inch

For maximum strength when milling harder materials where rapid swarf removal is not needed. 4 flute milling cutters have one of the strongest tooth structures available in solid cutters. Centre cutting as standard. Manufactured to Ansi Standards.
Inch Tolerances
Nominal Limits Of Tolerance
Diameter High Low
1/16" - 1/4" 0.000 -0.002
17/64" - 1" 0.000 -0.003
Metric Tolerances
Nominal Limits Of Tolerance
Diameter High Low
1 - 6 0.000 -0.050
7 - 25 0.000 -0.080

Kennedy® Milling Cutters Plain Shank Carbide Micrograin

3 Flute
Centre cutting as standard. Offer a combination of advantages achieved with two and four flutes giving profile and peripheral milling capability in addition to slotting and plunging. Manufactured to Works Standards.

For all dimensional and technical specifications please refer to our catalogue.

Regular Series 3 Flute Slot Drills - Metric

Sherwood 4, 6 & 8 Flute End Mills Threaded Shank HSS

Used for profile milling and producing open slots. Bright finish. Flute type : 30° Helix. Manufactured to BS 122 : Part 4 : 1980.

Long Series E430T - Metric

For all dimensional specifications please refer to our catalogue.
