577 - Thread Sealant

Medium strength. Suitable for copper, mild steel, cast iron, stainless steel and galvanised pipe. Carries the German DVGW approval. tested in accordance with EN751-1. Certified to NSF P1. Conforms with: BS 6956 : 7 (gas).
AGA Approval No. 3207 to 1050kPa (152psi).

572 - Thread Sealant - Coarse Threads - Slow Cure

Recommended for all coarse threads where slow cure is required to allow final adjustment before sealing. Meets BS 6956 Type A for sealing gas fittings. WRC approved for use with potable water.

5800 Medium Strength Gasketing Sealant

LOCTITE® 5800 is a single component, medium strength, anaerobic sealant which cures when confined in the absence of air between close fitting metal surfaces. Typical applications include sealing close fitting joints between rigid metal faces and flanges. The product provides resistance to low pressures
immediately after assembly of flanges. Typically used as a form-in-place gasket on rigid flanged connections, e.g. gearbox and engine casings, etc.



Benefits:
• Leading in Health & Safety
• No hazard symbols, no risk phrases & no safety phrases
• “White” Material Safety Data Sheet – no entries in sections
2, 3, 15 and 16 of MSDS acc. to (EC) No. 1907/2006 – ISO
11014-1
• Excellent chemical and thermal resistance of cured product

Technical Data:
• Colour: Red
• Service temperature range: -50°C to +180°C
• Tensile shear strength: 12 N/mm²
• Max. gap: 0.3 mm
• Max Fixture time steel: 25min.
• Strength: Medium
• Cure method: Anaerobic
Pack size: 50ml

6300 High Strength Retaining Compound

LOCTITE® 6300™ is designed for the bonding of cylindrical fitting parts. The product cures when confined in the absence of air between close fitting metal surfaces and prevents loosening and leakage from shock and vibration. Typical applications include holding gears and sprockets onto gearbox shafts and rotors on electric motor shafts.



Technical Data:
• Diametrical clearance: Up to 0.15mm
• Service temperature range: -55°C to + 175°C
• Tensile shear strength: 20 N/mm²
• Fixture time on steel: 10 min.
• Pack size: 50ml

Benefits:
• Leading in Health & Safety
• No hazard symbols, no risk phrases & no safety phrases
• oeWhite” Material Safety Data Sheet ?? no entries in sections
2, 3, 15 and 16 of MSDS acc. to (EC) No. 1907/2006 ?? ISO
11014-1 Good thermal resistance

Plasti-Coll X10 Gas Jointing Compound

Originally developed to meet the requirements of the liquified petroleum industry for fitting pipes and has been used for years in the assembly and installation of appliances that use natural gas, bottled propane or butane. Reddish brown in colour. Temperature resistant -40C to 200C. Conforms to BS695: Parts 5 & 6 Type 'A' : 1992

Stag Jointing Compound

Easy break, smooth consistency, lead-free jointing compounds. Type 'A' Thin consistency, for small joints which are new or undamaged. Type 'B' Thick consistency, for use on uneven surfaces.

PTFE Tape

General purpose tape for sealing gas/water pipe threads. Chemical and acid resistant. For use at temperatures from -270C to 260C.

Gas Type

5mtr x 12mm roll. For gas and hot water pipes (not for potable water). Satisfies BGC IM/16 BS6974:1989 and BS5292 type C tests.
